DOBOT APPLICATIONS IN THE CONSTRUCTION INDUSTRY
Manpower is a very limited resource here in Singapore. Using robots, we can shorten the time to construct buildings. Robots could be used in precise placements of MEP systems in PPVC module to reduce time taken to install them as well as assembly of prefabricated facades.
BASE BLOCKLY CODE AND VIDEO PROTOTYPE
Using blockly programming, I created this stacking prototype with the DOBOT placing a block on top of a base object and is followed by another block placed on top of the other. To push the DOBOT's precision, I stacked the blocks on the narrow width.
FUTURE OPTIMISATION
In the future, i could remove the double rotation of the arm in the beginning i originally input to increase accuracy of the block grabbing. In real life scenarios, the white blocks would not be put there manually but can be placed through conveyer belts or another robotic arm.
INSTALLATION OF MEP SYSTEMS IN PPVC MODULES
CURRENT INDUSTRY PRACTICE
MEP systems are constructed in PPVC modules in the form of ducts, pipes and plumbing as shown in the diagram below
APPLICATION OF DOBOT
Robots could be used in precise placements of MEP systems in PPVC module to reduce time taken to install them
3D animation showing how MEP systems can be installed on the ceiling of modules
PREFABRICATED LAYERED FACADES
APPLICATION OF DOBOT
Robots could be used in precise placements and assembly of prefabricated layered facades with Cladding/Louvers/insulation/etc.
3D animation showing how layered facades can be constructed remotely and installed in a building.
